New Sen Hi-Speed Automatic Label Die Cut Machine (Double Head)
New Sen Hi-Speed Automatic Label Die Cut Machine (Double Head)
Model
Sen SDH-350S
Description
| Model : | Sen SDH-350S (Servo Drive Motor, Digital Feed Length, System) |
| Min./ Max. Paper Web Width : | 30-350mm |
| Max. Die Cutting Size : | (L) 330mm X (W) 330mm |
| Max. Hotstamping Size : | (L) 300mm X (W) 300mm |
| Die Cut Unit : | 1 |
| Hotstamping Station : | 1 |
| Waste Paper Auto Rewind : | 1 |
| Waste Paper Mechanical Rewind : | 1 |
| Second Pass Scanner Mark Sensor : | 1 |
| Laminating with Unwind & Rewind (Ø300mm) : | 1 |
| Unwinder & Rewinder (Ø550mm) : | 1 |
| Hotstamping Unwinder Diameter (Ø150mm) : | 1 |
| Hotstamping Rewinder Diameter (Ø300mm) : | 1 |
| Repeat Length : | 330mm |
| Machine Speed : | 400rpm/min ~ 24,000/hour |
| Power Required : | 3 phase 220V 50/60HZ ~ 8KW 10KVA 30A |
| Net Weight : | 3,000 kgs |
| Machine Dimension : | (L) 3,300mm X (W) 1,200mm X (H) 1,800mm |
